Nexans U-1000 AR2V

Nexans U-1000 AR2V Nexans U-1000 AR2V

Nexans U-1000 AR2V

Low voltage power cable for fixed application

Nexans U-1000 AR2V and Nexans TWISTAL U-1000 AR2V cables, 100% manufactured in France (plant Jeumont 59), guarantee a minimum 35% reduction in greenhouse gas emissions compared to standard cables.
This offer is built on the guaranteed use of low-carbon aluminium and recycled plastic, as well as the use of renewable or decarbonised energies in manufacturing the cables.
Nexans provides all the environmental data for its products (PEP Ecopassport®)

Read more
Download all documents
Contact us

Products

Actions
Filters

  • products

Nexans U-1000 AR2V 1x25

Nexans ref. 10057424 - Country ref. 01362080

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 25 mm²



Nexans U-1000 AR2V 1x35

Nexans ref. 10044029 - Country ref. 01362080

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 1x50

Nexans ref. 10043984 - Country ref. 01362090

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 1x70

Nexans ref. 10043985 - Country ref. 01362100

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 70 mm²



Nexans U-1000 AR2V 1x95

Nexans ref. 10043986 - Country ref. 01362110

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 95 mm²



Nexans U-1000 AR2V 1x120

Nexans ref. 10043987 - Country ref. 01362120

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 120 mm²



Nexans U-1000 AR2V 1x150

Nexans ref. 10043988 - Country ref. 01362130

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 150 mm²



Nexans U-1000 AR2V 1x185

Nexans ref. 10043989 - Country ref. 01362140

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 185 mm²



Nexans U-1000 AR2V 1x240

Nexans ref. 10043990 - Country ref. 01362150

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 240 mm²



Nexans U-1000 AR2V 1x300

Nexans ref. 10043991 - Country ref. 01362160

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 300 mm²



Nexans U-1000 AR2V 1x400

Nexans ref. 10043992 - Country ref. 01362170

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 400 mm²



Nexans U-1000 AR2V 1x500

Nexans ref. 10044013 - Country ref. 01362080

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 500 mm²



Nexans U-1000 AR2V 1x630

Nexans ref. 10044014 - Country ref. 01362190

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 1
  • Conductor cross-section: 630 mm²



Nexans U-1000 AR2V 2x25

Nexans ref. 10057428 - Country ref. 01362270

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 2
  • Conductor cross-section: 25 mm²



Nexans U-1000 AR2V 2x35

Nexans ref. 10098424 - Country ref. 01363001

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 2
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 2x50

Nexans ref. 10057434 - Country ref. 01363001

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 2
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 3x16

Nexans ref. 10205980 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 16 mm²



Nexans U-1000 AR2V 3x25

Nexans ref. 10057450 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 25 mm²



Nexans U-1000 AR2V 3x35

Nexans ref. 10057451 - Country ref. 01362400

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 3G35

Nexans ref. 10057422 - Country ref. 01362400

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 3x50

Nexans ref. 10057430 - Country ref. 01362490

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 3G50

Nexans ref. 10177896 - Country ref. 01362490

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 3x70

Nexans ref. 10043993 - Country ref. 01362500

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 70 mm²



Nexans U-1000 AR2V 3G70

Nexans ref. 10175971 - Country ref. 01362500

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 70 mm²



Nexans U-1000 AR2V 3x95

Nexans ref. 10044012 - Country ref. 01362510

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 95 mm²



Nexans U-1000 AR2V 3G95

Nexans ref. 10175972 - Country ref. 01362510

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 95 mm²



Nexans U-1000 AR2V 3x120

Nexans ref. 10057431 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 120 mm²



Nexans U-1000 AR2V 3x150

Nexans ref. 10057425 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 150 mm²



Nexans U-1000 AR2V 3x185

Nexans ref. 10057432 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 185 mm²



Nexans U-1000 AR2V 3x240

Nexans ref. 10057426 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 240 mm²



Nexans U-1000 AR2V 3x300

Nexans ref. 10057453 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 300 mm²



Nexans U-1000 AR2V 3x400

Nexans ref. 10057396 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 3
  • Conductor cross-section: 400 mm²



Nexans U-1000 AR2V 4G25

Nexans ref. 10057449 - Country ref. 01362670

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 25 mm²



Nexans U-1000 AR2V 4x25

Nexans ref. 10057463 - Country ref. 01362675

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 25 mm²



Nexans U-1000 AR2V 4G35

Nexans ref. 10057448 - Country ref. 01362600

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 4x35

Nexans ref. 10043983 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 4x50

Nexans ref. 10043994 - Country ref. 01362690

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 3x50+35

Nexans ref. 10057443 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 4G50

Nexans ref. 10057397 - Country ref. 01362690

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 4x70

Nexans ref. 10043995 - Country ref. 01362700

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 70 mm²



Nexans U-1000 AR2V 3x70+50

Nexans ref. 10043997 - Country ref. 01362890

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 70 mm²



Nexans U-1000 AR2V 4G70

Nexans ref. 10205655 - Country ref. 01362700

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 70 mm²



Nexans U-1000 AR2V 4x95

Nexans ref. 10043996 - Country ref. 01362710

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 95 mm²



Nexans U-1000 AR2V 3x95+50

Nexans ref. 10043998 - Country ref. 01362900

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 95 mm²



Nexans U-1000 AR2V 4G95

Nexans ref. 10204292 - Country ref. 01362710

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 95 mm²



Nexans U-1000 AR2V 3x120+70

Nexans ref. 10043999 - Country ref. 01362920

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 120 mm²



Nexans U-1000 AR2V 4x120

Nexans ref. 10057460 - Country ref. 01362730

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 120 mm²



Nexans U-1000 AR2V 4G120

Nexans ref. 10057459 - Country ref. 01362730

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 120 mm²



Nexans U-1000 AR2V 4x150

Nexans ref. 10057458 - Country ref. 01362730

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 150 mm²



Nexans U-1000 AR2V 3x150+70

Nexans ref. 10044000 - Country ref. 01362940

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 150 mm²



Nexans U-1000 AR2V 4G150

Nexans ref. 10057461 - Country ref. 01362730

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 150 mm²



Nexans U-1000 AR2V 3x185+95

Nexans ref. 10044001 - Country ref. 01362960

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 185 mm²



Nexans U-1000 AR2V 3x185+70

Nexans ref. 10057447 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 185 mm²



Nexans U-1000 AR2V 4x185

Nexans ref. 10057439 - Country ref. 01362710

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 185 mm²



Nexans U-1000 AR2V 4G185

Nexans ref. 10057332 - Country ref. 01362710

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 185 mm²



Nexans U-1000 AR2V 4x240

Nexans ref. 10057440 - Country ref. 01362750

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 240 mm²



Nexans U-1000 AR2V 3x240+95

Nexans ref. 10044002 - Country ref. 01362970

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 240 mm²



Nexans U-1000 AR2V 3x240+150

Nexans ref. 10069329 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 240 mm²



Nexans U-1000 AR2V 4G240

Nexans ref. 10057462 - Country ref. 01362750

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 240 mm²



Nexans U-1000 AR2V 3x300+150

Nexans ref. 10057395 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: Yes
  • Number of cores: 4
  • Conductor cross-section: 300 mm²



Nexans U-1000 AR2V 4x300

Nexans ref. 10057441 - Country ref. 01362710

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 4
  • Conductor cross-section: 300 mm²



Nexans U-1000 AR2V 5G16

Nexans ref. 10088324 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 5
  • Conductor cross-section: 16 mm²



Nexans U-1000 AR2V 5G25

Nexans ref. 10057464 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 5
  • Conductor cross-section: 25 mm²



Nexans U-1000 AR2V 5G35

Nexans ref. 10204354 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 5
  • Conductor cross-section: 35 mm²



Nexans U-1000 AR2V 5G50

Nexans ref. 10204355 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 5
  • Conductor cross-section: 50 mm²



Nexans U-1000 AR2V 5G70

Nexans ref. 10204356 - Country ref. 01362680

  • Packaging: Cut to length (m)
  • With smaller neutral conductor: No
  • Number of cores: 5
  • Conductor cross-section: 70 mm²



Description

Description

Standards

  • Product
    IEC 60228; IEC 60502-1; NF C32-321

Application

Nexans U-1000 AR2V aluminium cables can be used in all low voltage power installations.

Our range also offers Nexans TWISTAL®, the twisted single-core version of Nexans U-1000 AR2V, specially designed to make three-phase links with neutral. Nexans TWISTAL® simplifies your life and offers many advantages :

  • Each core is spotted with a color band
  • The twisted core reduces the number of drums and cables pulling
  • This solution can allow to reduce the section of used cables (in parallel circuits)
  • Nexans TWISTAL® is more flexible and light than a multiconductor, allowing to increase comfort and saving of time

Installation

These cables can be fixed on cable trays, within conduits or fixed to walls.
They also can be buried directly with extra mechanical protection.

Design

  • Conductor: stranded circular aluminium - class 2
  • Insulation: XLPE - cores identification by colours
  • Laying up (for multi conductors): with non hygroscopic filler
  • Outer sheath : Lead free black PVC

Construction according to AD8 is possible on request



Marking

N (x ou G) S mm² U-1000 AR2V NF - USE N° Usine S.Y + Sans Pb

  • N = number of cores
  • S = section in mm²
  • G = with Green-Yellow
  • x = without Green-Yellow





Without mechanical protection, those cables can be fixed on the wall, cables trays or cable laders.

In buildings with explosion risks, they will be installed with particular protection. In this case, step down of 15% current carrying capacities.



Pulling on cable conductors

Tensile stress per mm2 of globale section shall in no case exceed 3 daN for LV aluminium cable.

The maximum pulling load must never exceed 2000 daN even rule above-mentionned sometimes leads to higher values for large section of cable.

Low carbon offer

Low carbon at a glance

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Conductor material
Aluminum
Conductor flexibility
Stranded class 2
Insulation
XLPE (chemical)
Outer sheath
PVC
Sheath colour
Black
Lead free
Yes
Conductor shape
Circular

Electrical characteristics

Electrical characteristics

Rated Voltage Uo/U (Um)
0.6/ 1 (1.2) kV

Mechanical characteristics

Mechanical characteristics

Cable flexibility
Rigid
Mechanical resistance to impacts
Good

Usage characteristics

Usage characteristics

Max. conductor temperature in service
90 °C
Short-circuit max. conductor temperature
250 °C
Operating temperature, range
-25 ... 60 °C
Weather resistance
AN3
Chemical resistance
Accidental
Flame retardant
C2, NF C 32-070
Water proof
Intermittent
